The World's Leading Drilling Technology
Sort By Hole Size
Product Type
Hole Ranges
Applications
Patriot 80
Hole Size: 7.875 to 10" (200mm to 254mm)
Hammer Outside Diameter: 7.125 (181mm)
Bit Shank: 380
Connection Size: 4.5 API REG PIN
Download Product Brochure
Patriot 85
Hole Size: 7.875 to 10" (200mm to 254mm)
Hammer Outside Diameter: 7.125 (181mm)
Bit Shank: 380
Connection Size: 4.5 API REG PIN
Download Product Brochure
Patriot 85Q
Hole Size: 7.875 to 10" (200mm to 254mm)
Hammer Outside Diameter: 7.125 (181mm)
Bit Shank: QL80
Connection Size: 4.5 API REG PIN
Download Product Brochure
DCS5
Hole Size: 5.5 to 6.125" (140mm to 156mm)
Hammer Outside Diameter: 4.875 (124mm)
Bit Shank: QL50
Connection Size: 3.5 API REG PIN
Download Product Brochure
DCS5HD
Hole Size: 5.75 to 6.25" (146mm to 159mm)
Hammer Outside Diameter: 5 (127mm)
Bit Shank: QL50
Connection Size: 3.5 API REG PIN
Download Product Brochure
Patriot 50
Hole Size: 5.5 to 6.125" (140mm to 156mm)
Hammer Outside Diameter: 4.875 (124mm)
Bit Shank: QL50
Connection Size: 3.5 API REG PIN
Download Product Brochure
Patriot 60W
Hole Size: 6 to 8.75" (152mm to 222mm)
Hammer Outside Diameter: 5.5 (140mm)
Bit Shank: 360
Connection Size: 3.5 API REG PIN
Download Product Brochure
Patriot 60
Hole Size: 6 to 8.75" (152mm to 222mm)
Hammer Outside Diameter: 5.5 (140mm)
Bit Shank: QL60
Connection Size: 3.5 API REG PIN
Download Product Brochure
Patriot 60HD
Hole Size: 6.25 to 8.75" (159mm to 222mm)
Hammer Outside Diameter: 5.75 (146mm)
Bit Shank: QL60
Connection Size: 3.5 API REG PIN
Download Product Brochure
Patriot 45
Hole Size: 4.5 to 5.25" (114mm to 133mm)
Hammer Outside Diameter: 4 (102mm)
Bit Shank: TD40
Connection Size: 2.375 API REG PIN
Download Product Brochure
Patriot 35A
Hole Size: 3.5 to 4.125" (89mm to 105mm)
Hammer Outside Diameter: 3.125 (79mm)
Bit Shank: C35/3.5
Connection Size: 2.375 API REG PIN
Download Product Brochure
Patriot 40
Hole Size: 4.25 to 5.25" (108mm to 133mm)
Hammer Outside Diameter: 3.75 (95mm)
Bit Shank: 340A
Connection Size: 2.375 API REG PIN
Download Product Brochure
Patriot 40HD
Hole Size: 4.25 to 5.25" (108mm to 133mm)
Hammer Outside Diameter: 3.875 (98mm)
Bit Shank: 340A
Connection Size: 2.375 API REG PIN
Download Product Brochure
